Case of the week Details

A: Postcholecystectomy status
T2WI shows a fluid collection in the gall bladder fossa with dilatation of bilobar intrahepatic biliary radicles

B.-T2WI shows narrowing noted involving the hepatic duct and primary biliary confluence for a length of 1.4 cm

C.- MRCP shows a suspicious communication between the gall bladder fossa collection and left hepatic duct

Post operative Iatrogenic biliary duct injury with bile leak

(Strasberg classification – Type E- E4 )

Discussion:

• Iatrogenic bile duct injuries (IBDI) remain an important problem in gastrointestinal surgery.
• They are most frequently caused by laparoscopic cholecystectomy, which is one of the commonest surgical procedures in the world.
• The early and accurate diagnosis of IBDI is very important for surgeons and gastroenterologists, because unrecognized IBDI lead to serious complications such as biliary cirrhosis, hepatic failure and death
• IBDI present about 95% of all benign biliary strictures

Clinical presentation:

The common clinical symptoms are jaundice, fever, chills, and epigastric pain

Jaundice is observed in patients with stricture rather than bile leak

Diangnostic approach:

• Imaging diagnostics in IBDI involve ultrasonography of the abdominal cavity, cholangiography, endoscopic retrograde cholangiopancreatography (ERCP), computed tomography, and magnetic resonance-cholangiography.
• Magnetic resonance cholangiography is a sensitive (85%-100%) and non-invasive imaging modality for the biliary tract. Currently, it is the “gold standard” in preoperative diagnosis of IBDI in patients qualifying for surgical reconstruction

CLASSIFICATION OF IBDI:

• The Strasberg classification of bile duct injuryis a widely used system to anatomically define these injuries by location

Classification

• type A: injury to the cystic duct or from minor hepatic ducts draining the liver bed
• type B: occlusion of the biliary tree, commonly aberrant right hepatic duct(s)
• type C: transection without ligation of aberrant right hepatic duct(s)
• type D: lateral injury to a major bile duct
• type E: injury to the main hepatic duct; classified according to the level of injury
  • E1 (Bismuth type 1): injury more than 2 cm from the confluence
  • E2 (Bismuth type 2): injury less than 2 cm from the confluence
  • E3 (Bismuth type 3): injury at the confluence; confluence intact
  • E4 (Bismuth type 4): destruction of the biliary confluence
  • E5 (Bismuth type 5): injury to the aberrant right hepatic duct

Surgical management:

Different surgical reconstructions are performed in patients with IBDI. According to the literature, Roux-en-Y hepaticojejunostomy is the most frequent surgical reconstruction and recommended by most authors. In the opinion of some authors, a more physiological and equally effective type of reconstruction is end-to-end ductal anastomosis.

Conclusion

• Iatrogenic bile duct injuries remain an important problem in gastrointestinal surgery.
• They are most frequently caused by laparoscopic cholecystectomy, which is one of the commonest surgical procedures in the world.
• Clinical symptoms like jaundice is observed in patients with stricture rather than bile leak
• The Strasberg classification of bile duct injuryis a widely used system to anatomically define these injuries by location

References

• Strasberg S, Strasberg HM, Strasberg SN, Strasberg. An Analysis of the Problem of Biliary Injury During Laparoscopic Cholecystectomy. (1995) Journal of the American College of Surgeons. doi:– Pubmed
• Bernhard W. Renz, Florian Bösch, Martin K. Angele. Bile Duct Injury after Cholecystectomy: Surgical Therapy. (2020) Visceral Medicine. 33 (3): 184. doi:10.1159/000471818– Pubmed
• Hariharan D, Hariharan PE, Hariharan SJ, Hariharan LD, Hariharan. Quality of Life and Medico-Legal Implications Following Iatrogenic Bile Duct Injuries. (2017) World journal of surgery. doi:10.1007/s00268-016-3677-9– Pubmed
• Archer SB, Brown DW, Smith CD, Branum GD, Hunter JG. Bile duct injury during laparoscopic cholecystectomy: results of a national survey. Ann Surg. 2001;234:549–558; discussion 558-559. [PMC free article] [PubMed] [Google Scholar]
• Negi SS, Sakhuja P, Malhotra V, Chaudhary A. Factors predicting advanced hepatic fibrosis in patients with postcholecystectomy bile duct strictures. Arch Surg. 2004;139:299–303. [PubMed] [Google Scholar]
• Pellegrini CA, Thomas MJ, Way LW. Recurrent biliary stricture. Patterns of recurrence and outcome of surgical therapy. Am J Surg. 1984;147:175–180. [PubMed] [Google Scholar]

Dr. JAISHILPA
Senior Consultant Radiologist
Manipal Hospital, Yeshwanthpur, Bengaluru.

Dr. SHARNITHA JOHNSON
Senior Resident
Manipal Hospital, Yeshwanthpur, Bengaluru.
